Cell divided high voltage laboratory

A flexible laboratory with ca. 15 test cells that easily can be changed when needed. The laboratory is electromagnetic shielded and typically voltages are up to 200 kV DC and 200 kV AC. The laboratory is used for experiments like:

-Long and short term testing/ageing of insulation materials and components
-Partial Discharge testing

Pictures

 Lab photoLab photo
